| 主要技(ji)術參數 | TECHNICAL DATA | UNIT | YP6209 |
| 最大壓制力 | Max.Pressing Force | kN | 62000 |
| 最大頂出力 | Max.Ejecting Force | kN | 275 |
| 動(dong)梁(liang)最(zui)大行程(cheng) | Max.Plunger Stroke | mm | 215 |
| 動梁下平面(mian)與工作(zuo)臺面(mian)最(zui)小間距(ju) | Min.Distance between Press Plunger and Table | mm | 510 |
| 動梁(liang)下(xia)平面(mian)與(yu)工作臺面(mian)最大間距 | Max.Distance between Press Plunger and Table | mm | 725 |
| 左右立柱(zhu)間凈空 | Clearance between Columns | mm | 1950 |
| 動梁工作面前后寬度 | Useful Width of Plunger | mm | 1220 |
| 工作臺(tai)面前后寬度 | Width of Press Table | mm | 1400 |
| 最大填(tian)料深度 | Max.Filling Depth | mm | 70 |
| 空循環(huan)次數可達 | Working Cycles in idle Stroke | mm-1 | 16 |
| 周(zhou)期(qi)中加壓次數 | Strokes Per Cycle | times | 2～5 |
| 主電機功率 | Power of the Main Motor | kW | 160 |
| 系統裝(zhuang)油量 | System Oil Capacity | L | 1750 |
| 系統耗氣量 | Air Consumption | m3/h | 0.4 |
| 常溫(wen)水(shui)流量 | Water Consumption at 24℃ | m3/h | 20 |
| 主機重量(liang) | Weight of the Press Body | t | 133 |
